What are the parts inside a toilet? The anatomy of a toilet

A standard gravity toilet has two main assemblies: the tank on the back and the bowl underneath, joined by bolts and a gasket. Everything that makes it flush is either inside the tank or under the bowl. The anatomy of a toilet is simple once you see it as a water-storage tank feeding a siphon.

Think of the tank as a reservoir, the bowl as the receiving fixture and the trapway as the built-in S-shaped curve that holds a water seal against sewer gas. Water enters through the supply line, fills the tank, and drops into the bowl when you push the handle. The weight and speed of that water pushes waste through the trapway and into the drain.

Toilet diagram in words: front to back

Picture the fixture from the floor up. A closet flange is bolted to the floor and receives the drain pipe. A wax ring or a rubber seal sits between the flange and the bowl horn. The bowl sits on that seal, held by two closet bolts with caps. The tank rides on the back of the bowl on tank bolts and a large rubber gasket. Inside, the flush valve, the flapper or canister, the overflow tube and the fill valve do the work. The supply line and shutoff valve, called the angle stop, connect the toilet to the house.

Terms people use for the same thing

People search for toilet parts under different names: commode, WC, water closet, reservoir, cistern. Parts of the commode and toilet pieces are the same as the parts of the toilet. The tank is also called the toilet reservoir, and the flush lever is the trip lever. Using the right term helps when you ask a plumber or a supplier for the exact item.

Toilet tank parts and how they work

The toilet tank parts are the flush valve, flapper, fill valve, float, overflow tube, trip lever and refill tube. Together they store water, release it on command and refill the tank to the correct level. When one of these wears out, you get a running toilet, a phantom flush or a weak flush.

Components of a toilet tank, one by one

The components of a toilet tank each have a single job, and most fail in a predictable way.

• Flush valve: the large opening at the bottom of the tank that lets water rush into the bowl. Its seat can pit or gather mineral scale.
• Flapper: the rubber seal that covers the flush valve. It softens, warps or grows slime with age and chemicals.
• Fill valve: the tall assembly on the left side that lets water in and stops at the set level.
• Float: a cup or ball that rises with the water and tells the fill valve when to close.
• Overflow tube: a vertical pipe that protects the bathroom from overfilling by draining excess into the bowl.
• Trip lever and chain: connect the handle to the flapper; a chain that is too tight or too loose causes trouble.
• Refill tube: a small hose that sends a little water down the overflow to refill the bowl after a flush.

Parts for inside toilet tank: what commonly wears out first

The parts inside a toilet tank that fail most often are the flapper and the fill valve, because they move every day and sit in water constantly. A tank that runs on and off by itself usually has a flapper leak. A tank that hisses, or that never quite fills, usually points to the fill valve or a clogged supply screen.

Toilet bowl parts and the back of the toilet

The toilet bowl parts you can see are the seat, lid, bowl rim and base; the parts you cannot see are the siphon jet, the trapway and the seal at the floor. The visible seat hinges and covers are simple to swap, while the hidden parts decide whether the toilet flushes well or leaks.

Toilet bowl tank parts: how the two halves connect

The toilet bowl tank parts that join the two halves are the tank bolts, rubber washers and the spud gasket. When those washers harden, water seeps from the base of the tank and drips on the floor. That looks like a leak at the wall or the bowl, so it is easy to misdiagnose. Snug the nuts evenly by hand and a small wrench; over-tightening can crack the porcelain, so stop at snug.

Back of toilet: supply line, shutoff and wall connection

The back of toilet is where you find the shutoff valve, the braided supply hose and, on many models, the flush handle side connection. A shutoff that will not turn all the way, or that weeps at the stem, is worth replacing before you start any other repair.

Common problems and how to spot them

The most common toilet problems are running water, weak or incomplete flushing, slow refilling, clogs, leaks at the base and a rocking bowl. Each has a typical cause, and matching the symptom to the part saves time and money.

• Runs continuously: worn flapper, chain that is too short, or fill valve that will not shut off.
• Weak flush: low tank water level, partly blocked rim jets, or a partial clog in the trapway.
• Slow refill: clogged fill valve screen, a half-open shutoff, or a failing fill valve.
• Water around the base: failed wax ring, loose closet bolts, or condensation on a cold tank.
• Rocking bowl: loose bolts, an uneven floor, or a damaged flange.
• Gurgling in other fixtures when you flush: a drain or vent problem beyond the toilet.

For a deeper walk-through of the first three, see toilets that are not flushing, running or refilling.

How to fix a running toilet and other tank problems

Fixing a toilet that runs starts with the tank, not the bowl. Shut off the water at the angle stop, flush to empty the tank, and inspect the flapper, chain and fill valve. Most tank fixes take a screwdriver, an adjustable wrench and a replacement part.

Fixing toilet tank problems, step by step

Fixing toilet tank trouble follows the same order each time.

1. Remove the tank lid and set it somewhere safe on a towel.
2. Add a few drops of food coloring to the tank, wait fifteen minutes without flushing, and check whether color appears in the bowl. If it does, the flapper leaks.
3. Check the chain has a little slack, not tight and not tangled.
4. Look at the water level against the mark on the tank or the fill valve; adjust the float if it sits above the overflow tube.
5. Shut off the supply, replace the flapper or fill valve, and restore water slowly.

How to fix commode and WC problems in general

Searches such as how to fix commode and how to fix WC describe the same repair sequence: identify whether the trouble is at the flapper, the fill valve, the handle or the seal at the floor. If you are repairing toilets in a home with old brass or galvanized supply lines, expect stubborn nuts and do not force them. A plumber can replace the shutoff and the supply hose in the same visit as part of ordinary plumbing repair.

Toilet tank repair versus a new tank

Toilet tank repair is nearly always cheaper than replacing the tank, but a hairline crack in porcelain cannot be repaired reliably. A crack that weeps, or a tank that is stained around the base and bolts, usually calls for a new tank or a new toilet. Commode tank repair of a chipped or crazed glaze is cosmetic; a crack through the wall is not.

Toilet replacement parts: what to buy and what to avoid

Toilet replacement parts are sold as universal kits and as model-specific parts, and the right choice depends on the age and design of your toilet. Universal flappers and fill valves fit most modern two-piece toilets, but odd flush valve sizes and older designs need matching parts.

Toilet repair parts and toilet tank replacement parts

Common toilet repair parts include the flapper, fill valve, flush valve seal, tank-to-bowl gasket, bolts and washers, and a wax ring. Toilet tank replacement parts also cover the trip lever, canister style flush valves and refill tubes. Photograph the inside of your tank and note the model stamped there before you shop; similar parts can differ in flush valve size.

Toilet hardware, supplies and bowl hardware

Toilet hardware means the small metal and plastic items: closet bolts, caps, washers, tank bolts, trip levers and mounting kits. Toilet bowl hardware at the floor should be stainless or brass where possible, because plain steel rusts and seizes. Toilet supplies in a repair kit usually include a wax ring, shims and bolts, but confirm the ring suits your flange height before you buy.

Toilet plumbing parts to leave to a plumber

Some toilet plumbing parts, such as a corroded shutoff that will not close or a cracked flange, deserve professional handling.

Toilet flange repair and floor leaks

Toilet flange repair is the fix for the ring that connects the toilet drain to the floor pipe. A damaged, rusted or loose flange lets the toilet rock, leaks at the base, and can allow sewer gas into the room. The flange must be firmly anchored to the subfloor and sit at the right height relative to the finished floor.

Toilet bowl flange repair: signs and causes

Signs that call for toilet bowl flange repair include:

• A bowl that rocks even with tight bolts.
• Repeated wax ring failures.
• Stains or soft flooring around the base.
• A flange that sits below the floor surface.

Causes include age, corrosion on cast iron flanges, cracks in plastic ones, and flooring added after the original install so the flange now sits too low.

What a plumber does to fix a flange

Repair may involve a flange extender or repair ring, replacing the flange, resecuring it to the subfloor, and setting a new wax ring or seal. If the subfloor is soft or rotted, it must be dealt with first. If water damage is nearby, consider leak detection when the source is not obvious.

Toilet leak repair: tank, supply line and base

Toilet leak repair starts with finding where the water actually comes from. Dry every surface with a towel, then wrap dry tissue around each joint and watch which one gets wet. Leaks come from one of three areas:

• The tank, at the bolts, gasket or fittings.
• The supply connection at the angle stop or hose.
• The base, where the bowl meets the floor.

Toilet tank leak repair

Toilet tank leak repair covers tank bolt washers, the spud gasket, the flush valve nut, the fill valve nut and cracks. Bolt washer leaks are the most common and the easiest to fix. A crack means replacement.

Leaks at the supply line and shutoff

A weeping compression nut may just need a quarter-turn. A braided hose that looks swollen, rusty or old is best replaced. When the angle stop leaks at the handle, change the valve rather than tightening the packing nut repeatedly.

Leaks at the base of the bowl

Water at the floor may be from a failed wax ring, a sweating tank, or a supply leak running down. If it is at the base after every flush, assume a seal problem. Stop using the toilet and shut off the supply, because water under flooring can ruin subfloor and ceilings below. A hidden source may be a water leak or pipe repair issue rather than the toilet. In a hurry, call emergency plumbing rather than mopping up repeatedly.

Toilet plumbing behind the wall: piping, drain and vent

Toilet plumbing includes the supply on one side and the waste on the other. The toilet piping brings in a small water line from the home's water lines and sends waste out through a much larger drain, commonly three or four inches. A vent pipe lets air in so the trap does not siphon empty and drains flow smoothly.

Toilet bowl plumbing and the trap

The toilet bowl plumbing starts at the trapway, the built-in curve that holds standing water as a barrier against sewer odors. When the trap is partly blocked, you get slow flushes, gurgles or a bowl that rises then falls. A plunger works on many soft clogs; an auger rated for toilets is better for deeper ones. If several fixtures back up together, the problem is in the main drain, not the toilet; see drain cleaning for that.

Pipe toilet connections and the main line

A pipe toilet connection at the floor ties into a branch that joins the main stack or the sewer lateral. Repeated backups, roots and sewage odors may call for a sewer camera inspection to look inside the line.

Toilet pump replacement, upflush units and pressure-assist systems

A toilet water pump is a term people use for several different things: an upflush macerating unit used where a drain cannot run by gravity, a pressure-assist tank that uses compressed air, or a pump in a basement bathroom. Toilet pump replacement depends on which one you own, so identify the type before ordering parts.

Toilet pump kit: what it usually includes

A toilet pump kit for an upflush system often includes the motor, switch, seals and a macerator blade, while a kit for a pressure-assist toilet may include a cartridge or vessel. Electrical components sit near water, so leave unit replacement to a professional; do not open a pressure-assist tank, because it holds stored air pressure.

Basement bathrooms and sump connections

Basement toilets that rely on pumps share risks with sump systems, which is why some homeowners ask about sump and well pump repair at the same visit.

Should you repair or replace the toilet?

Repair when the fixture is sound and the problem is a worn part; replace when the porcelain is cracked, the toilet needs constant attention, or the flush is poor by design. As a rough rule, one failed flapper is a repair, while cracks, a chronic clog and repeated seal failures point to a new toilet.

• Repair if the toilet is stable, uncracked and flushes strongly after a part swap.
• Replace if the bowl or tank has a structural crack.
• Replace if you have had several floor leaks or flange problems.
• Consider replacing if repair parts for an older model are hard to find.
• Consider replacing if you are remodeling and want a taller bowl or a different rough-in.

Toilet bowl repair: what can and cannot be fixed

Toilet bowl repair is limited: a clog, a loose seat or a leaking seal can be fixed, but cracked porcelain and a failed siphon jet often cannot. For the replacement route, read about toilet installation and replacement.

Toilet installation and toilet plumbing installation

Toilet installation means setting a new fixture on the flange with a new seal, connecting the supply and checking for leaks and stability. Toilet plumbing installation goes further when the bathroom layout changes: moving the drain, extending the vent, or adding a bathroom where there was none.

Toilet commode installation basics

A basic toilet commode installation involves shutting off water, removing the old fixture, inspecting the flange, setting the wax ring and bowl, tightening bolts evenly, mounting the tank, connecting the supply and testing. The rough-in distance from the wall to the drain center must match the new toilet.

When installation needs more than a swap

If the flange is damaged, the floor is uneven or the drain is out of position, the job grows. New bathrooms and layout changes are part of broader plumbing installation work, and toilets in a full renovation are covered in bathroom remodel plumbing.

When a toilet problem is an emergency

A toilet problem is an emergency when water keeps flowing and you cannot stop it, sewage is coming up, or water is reaching ceilings or electrical fixtures. Shut the angle stop first; if it will not close, shut the main water valve.

• Overflowing bowl: stop flushing, shut the supply, and do not use the fixtures downstream.
• Sewage backup: keep people and pets away, avoid contact, and do not mix drain chemicals.
• Water near outlets or a light fixture below: stay clear and shut off power at the breaker only if you can reach it dry and safely.

Availability for urgent calls, including "24 hour plumber" or "same day plumber" requests, is confirmed when you phone. For the full picture, see emergency plumbing near you.

Preventing toilet trouble

Most toilet problems can be reduced with small habits and a yearly look inside the tank. Flush only waste and toilet paper, and skip wipes labeled flushable.

• Inspect the flapper and chain once a year.
• Replace rubber parts that feel soft, sticky or warped.
• Exercise the angle stop occasionally so it does not seize.
• Avoid in-tank bleach tablets, which can attack rubber parts.
• Keep a spare flapper and fill valve on the shelf.
• Listen for hissing or refilling when nobody has flushed.

Hard water can leave scale in the fill valve and flush valve, so homes with mineral-heavy water may need parts changed more often. The same scale shortens the life of water heaters too.

Who to call and what it costs

Toilet repair cost varies with the part, access, the age of the fixture, whether the flange or floor is affected and the time of the call. Pricing is confirmed by phone after you describe the problem, and a good plumber will explain the cause before starting. For a general view of what shapes bills, see plumber cost factors, and for other fixtures, faucet and sink repair covers the kitchen side. See all plumbing services if the problem spans more than one fixture.

What to have ready when you call

• The make and model in the tank, if visible.
• Where the water appears and when it started.
• Whether the shutoff valve works.
• Photos of the tank interior and floor.
• The age of the home and any past toilet work.
